Beyond the Specs: What Is an Air Gap — and Why Does It Help?

The empty space behind your panel isn’t just empty.

Sound doesn’t just hit a panel and stop. It reflects, wraps, diffuses, resonates — and that’s where the air gap comes in.

Adding even a few centimeters of space behind an acoustic panel can radically improve how it performs — especially in the low to mid frequencies, where sound energy is more difficult to control.

Here’s why that invisible space matters.

Sound Energy Travels in Waves — Not Lines

Imagine a bass note. It doesn’t just move forward — it oscillates through air in long, slow waves. At lower frequencies (like 100–300Hz), the wavelength can be over a meter long.

If you place a panel directly on a wall, it mostly catches the high and mid frequencies. But low-end waves? They often reflect right back into the room.

An Air Gap Increases Absorption Depth — Without Adding Bulk

By spacing your panel off the wall — even 5cm to 10cm — you let those deeper waves enter, reflect inside, and dissipate energy more effectively.

But here’s the real trick:

Absorption is most effective when the panel sits where the wave’s velocity is highest.
That usually happens at one-quarter of the wavelength from a rigid surface (like a wall).

For example:

• At 250Hz, the wavelength is about 1.37m
• 1/4 of that = 34.3cm
• But even smaller gaps (~5–10cm) still interact with the wave’s pressure zone and boost absorption — especially when paired with porous materials.

Quick Reference: Quarter Wavelengths

So while we’re not building a perfect Helmholtz resonator here, the air gap gives you a tuned advantage — without extra thickness or weight.

Want more absorption without more bulk?
The space behind your panel helps trap deeper waves — using physics, not foam.

It’s like adding acoustic depth without physically thickening the panel. That’s why a 3cm panel with a 5cm gap can perform similar like an 8cm panel, especially in the 160–400Hz range.

In our test of the Surge panel with a ~3.5cm air gap, absorption began ramping up as early as 315Hz — earlier than typical wall-mounted configurations.

The Panel + Gap Acts as a System

Think of the panel and the air gap as a hybrid absorber:

• The panel handles higher frequencies
• The space lets lower frequencies bounce and slow
• Together, they perform like a tuned device — compact, efficient, and elegant

This is how we design at Massform. Every panel, every mount, and every surface is intentional.

The Panel + Gap Acts as a System

Think of the panel and the air gap as a hybrid absorber:

• The panel handles higher frequencies
• The space lets lower frequencies bounce and slow
• Together, they perform like a tuned device — compact, efficient, and elegant

This is how we design at massform. Every panel, every mount, and every surface is intentional.

 TL;DR:

Want more absorption without taking up more space?
Add a gap behind your panel.

It’s invisible. But powerful.
